GYC450– Elevator (Pitch) and Rudder (Yaw) Axis Gyro

---

Single Axis Aircraft Gyro AVCS/Normal (Pitch or Yaw - Twin Output)

---

FEATURES:

• Dedicated aircraft setup to help stabilise flight, including on demanding scale models.
• Suggested compatibility with elevator or rudder control, including twin-output use for two elevators or two rudders via S.BUS/S.BUS2.
• Suggested compatibility with elevon or V-tail mixing; two-axis control available by using two GYA450/GYA451 units with combined connection (S.BUS only).
• Remote gain function enables sensitivity adjustment from the transmitter and AVCS/Normal mode switching.
• On-unit gain trim for quick fine-tuning at the field.
• Easy to install with a compact, lightweight design aided by high-density mounting technology.
• Simple setup to get you flight-ready quickly.
• Excellent vibration resistance for use on models with large combustion engines.

The GYC450 has been designed for use with Futaba transmitters, receivers and servos.

SIZE:
21mm x 21mm x 11 mm
0.81 in x 0.81 in x 0.43 in

WEIGHT:
3.7 g
0.13 oz
